Kawasaki PRO-FX/PRO-FXT/PRO-FXR Mule Engine Rebuild Kit

Price$215.00

Kawasaki Mule 4000 / 4010 Air Filter Kit Replaces Kawasaki 11013-0037 & 11013-1290

Price$26.55

Kawasaki Mule 4000 / 4010 Air Filter Kit Replaces Kawasaki 11013-0037 & 11013-1290

Product ID KD1290/0037

Kit contains:
(1) OEM Air Filter Element: 11013-0037
(1) Aftermarket Air Filter Element Replacement for 11013-1290

Price$26.55

-
+

1 of 2

Kawasaki Bayou 300 4x4 Bevel Gear Case/Rear Shaft Oil Seal & O Ring Kit

Price$19.99

1 of 2

Kawasaki Bayou 300 4x4 Bevel Gear Case/Rear Shaft Oil Seal & O Ring Kit

Product ID KD1406

NEW Aftermarket Parts - Kawasaki Standard

Replaces: Oil Seal 654A304208 30 x 42 x 8 & O-Ring 92055-1406 47mm x 2.6mm

Fits Bayou 300 4x4 1989-2005

Fits on the Bevel Gear Case for Rear Shaft

Price$19.99

-
+

Kawasaki 3010/4010 Mule Diesel KAF950 Engine Piston Kit

Price$65.00

Kawasaki 3010/4010 Mule Diesel KAF950 Engine Piston Kit

Product ID KD1571

Kawasaki Diesel Mule KAF950 Engine Piston Kit

Includes 1 Piston (71.5mm), 1 Set of Rings, 1 Pin, 2 Clips
Replaces OEM #'s 13001-1571, 13008-1197, 92033-1314, 13008-1197

Price$65.00

-
+

Kawasaki Mule DIESEL 2510 3010 4010 Throttle Cable NEW - Replaces OEM 54012-1613

Price$24.99

Kawasaki Mule DIESEL 2510 3010 4010 Throttle Cable NEW - Replaces OEM 54012-1613

Product ID KD1613

Replaces OEM Kawasaki 54012-1613
THROTTLE CABLE

This item fits the following models:
2013 MULE 4010 4x4 Diesel
2012 MULE 4010 4x4 Diesel
2011 MULE 4010 4x4 Diesel
2010 MULE 4010 4x4 Diesel
2009 MULE 4010 4x4 Diesel
2008 MULE 3010 Diesel 4x4
2007 MULE 3010 Diesel 4x4
2006 MULE 3010 Diesel 4x4
2005 MULE 3010 Diesel 4x4
2004 MULE 3010 Diesel 4x4
2003 MULE 3010 Diesel 4x4
2002 MULE 2510 Diesel
2001 MULE 2510 Diesel
2000 MULE 2510 Diesel

For Single Cab / Diesel Only Mules

TOTAL LENGTH (END TO END) 96"

Price$24.99

-
+

Kawasaki Diesel Mule PRO-DX/PRO-DXT COMPLETE Drive Converter/Clutch Rebuild Ki

Price$385.00

Kawasaki Diesel Mule PRO-DX/PRO-DXT COMPLETE Drive Converter/Clutch Rebuild Ki

Product ID KD1670Weights-Springs

These parts will help you rebuild your (Primary) Drive Converter / Drive Clutch.

Rebuilds OEM Drive Converter 49093-0105, 49093-0106, 49093-0104 (Superseded #'s: 49093-0070, 49093-0069, & 49093-0050)

These parts will help you rebuild your (Primary) Drive Converter / Clutch.

Includes replacements for the most common worn parts.:
(1) Spider 49050-0565
(4) Weights 39152-0105
(1) Spring 92145-1670
(4) Weight Bushings 92139-1103 / 92139-1245
(4) Pins 92043-0809
(1) Bushing 92139-1244
(1) Bushing 92139-1243
(8) Shoes 49048-1090
(8) Nuts 92019-008
(1) O-Ring 92055-0789
(1) O-Ring 92055-0753

Repairs Kawasaki Mule PRO-DX / PRO-DXT ***Diesel ONLY

Price$385.00

-
+

Kawasaki Mule (KAF620) Valve Cover / Rocker Case with 2 Gaskets and 1 Oil Filler Cap

Price$35.00

Kawasaki Mule (KAF620) Valve Cover / Rocker Case with 2 Gaskets and 1 Oil Filler Cap

Product ID KD2068/2090Kit

Includes 2 gaskets for both Rocker Cases. Replaces OEM 11061-2182 &11060-2332
Our gaskets are the same material as OE but .02 mm thicker for better sealing. No more leaks!!

Includes Valve Cover / Rocker Case Replaces OEM 11022-2068 & 11022-2056

Includes Oil Filler Cap Replaces 16115-2090

Fits Kawasaki 2500, 2510, 2520, 3000, 3010, 3020, 4000, 4010 Mules (1993-2016)

Price$35.00

-
+

KAWASAKI MULE 500/520 / 550 (KAF300) ENGINE REBUILD GASKET KIT WITH PISTON, PISTON RINGS & SEALS

Price$99.00

KAWASAKI MULE 500/520 / 550 (KAF300) ENGINE REBUILD GASKET KIT WITH PISTON, PISTON RINGS & SEALS

Product ID KD2207

The kit includes: Piston, Piston Pin, Piston Rings, Oil Seals, Rocker Case Gasket, Carburetor Head Gasket, Head Gasket, Crankcase Cover Gasket & Muffler Gasket

Replaces OEM Part Numbers: 13001-2207, 13002-2069, 11060-2122, 11009-2829, 92049-2199, 92049-2220, 13008-6007, 11004-2138, 11009-2487, (2) 92049-2100, & 11009-2827

Fits All Kawasaki 500 / 520 / 550 Mules (KAF300 Engine)

Price$99.00

-
+

Kawasaki Mule KAF620 Engine Gasket Rebuild Kit w/ Piston, Rings, Camshaft & Connecting Rods

Price$499.00

Kawasaki Mule KAF620 Engine Gasket Rebuild Kit w/ Piston, Rings, Camshaft & Connecting Rods

Product ID KD326ConnectingRod

KAF620 Engine / John Deere FD620 / FD661 Rebuild Kit:

Includes:
Complete Aftermarket Gasket / Seal Kit
2 Sets of Standard Size Piston Rings - Replaces 13008-6025
2 Sets of Standard Size Pistons (75.9 MM) - Replaces 13001-2210
2 Pins - Replaces 13002-1013
4 Clips - Replaces 92036-021
1 Camshaft - Replaces 12044-2239
1 OEM 59051-2112 Spur Gear
2 OEM 92141-2122 Plane Bearings
1 Water Pump & Thermostat - Replaces 49044-2066 & 49054-2056
1 Oil Pump Kit - Replaces 59051-2114, 92145-1809, 16154-2053, 16154-2054, 49065-2072, 600A1300, 92042-014, 13107-2296
4 OEM 12032-2064 Tappets
4 OEM 49078-2082 Valve Springs
4 OEM 13116-2057 Push Rods
2 OEM 13251-0737 Connecting Rods

Fits the following Kawasaki Gas Mules:
2500, 2510, 2520, 3000, 3010, 3010, 3020, 4000, 4000, 4010, 4010 (1 & 2 Rows of Seats)
Fits the following John Deere Models: 425, 445, F911, & 6x4 Gator GX345

Price$499.00

-
+

Kawasaki 500 / 520 / 550 Mule Driven (Secondary) Converter / Clutch w/ Belt

Price$145.00

Kawasaki 500 / 520 / 550 Mule Driven (Secondary) Converter / Clutch w/ Belt

Product ID KD4-1054Belt

New Aftermarket (Secondary) Driven Converter / Clutch

Replaces # 49094-1054 (Superseded # 49094-1052 & 49094-1053)

Comes with OEM Drive Belt 59011-1055 / 59011-1071

Fits Kawasaki Mules 500 / 520 / 550 (KAF300)

Price$145.00

-
+

KD54010-0601 Aftermarket Shift Cable Kawasaki Mule Pro Series

Price$59.00

KD54010-0601 Aftermarket Shift Cable Kawasaki Mule Pro Series

Product ID KD54010-0601

KAF820 / KAF1000 Mule Heavy Duty Aftermarket Shift Control Cable

Replaces OEM 54010-0601

Fits Kawasaki Mule PRODX / PRODXT / PROFX / PROFXR / PROFXT

Cable dimensions: End to end 110 1/4" End to union 11 1/2" Outer threads of end screws 5.60 mm

Price$59.00

-
+

KAWASAKI MULE 500/520 / 550 (KAF300) FE290 ENGINE GASKET KIT

Price$39.00

KAWASAKI MULE 500/520 / 550 (KAF300) FE290 ENGINE GASKET KIT

Product ID KD550GASKET

Gasket Set Only, The kit includes: Oil Seals, Rocker Case Gasket, Carburetor Head Gasket, Head Gasket, Crankcase Cover Gasket & Muffler Gasket

Replaces OEM Part Numbers: 11060-2122, 11009-2829, 92049-2199, 92049-2220, 11004-2138, 11009-2487, (2) 92049-2100, & 11009-2827

Fits All Kawasaki 500 / 520 / 550 Mules (FE290 Engine)

Price$39.00

-
+

COMPLETE Kawasaki Diesel Mule Engine Rebuild Kit (.25MM OVER)

Price$625.00

COMPLETE Kawasaki Diesel Mule Engine Rebuild Kit (.25MM OVER)

Product ID KDG950OSPISTON

Kit includes all gaskets and seals to rebuild your diesel KAF950 Mule engine.

3 13029-1279 OVERSIZE Pistons (71.75mm)(OEM)
3 13002-1118 Piston Pins (OEM)
6 92033-1314 Piston Clips (OEM)
3 13025-1154 OVERSIZE Piston Rings Sets (OEM)
1 11060-1943 Oil Pan Gasket
1 11060-1947 Rear End Plate Gasket
3 92200-1507 Injection Nozz Washer
3 49091-1054 Washer Seal
2 11060-1942 Oil Drain Bolt Gasket
1 11004-1350 Head Gasket
1 11061-1101 Exhaust Manifold Gasket
1 11060-1954 Oil Filter Gasket
1 11060-1944 Rocker Case Gasket
1 11060-1945 Timing Cover Gasket
1 92055-1625 O-Ring
1 11060-1916 Exhaust Pipe Gasket
1 11060-1957 Water Pump Gasket
1 11060-1946 Timing Gear CA Gasket
1 11060-1958 Elbow Inlet Gasket
1 11060-1959 Elbow Outlet Gasket
1 92049-0106 Oil Seal
1 92049-0105 Oil Seal
6 92093-1521 Valve Stem Seal
3 11060-1962 Injection Nozz Gasket
1 11060-1915 Muffler Gasket
1 11060-1960 Intake Manifold Gasket

Price$625.00

-
+

Kawasaki 600 / 610 Mule Rear Axle Replacement Bearing & Seal Kit

Price$29.00

Kawasaki 600 / 610 Mule Rear Axle Replacement Bearing & Seal Kit

Product ID KDREARAXLE610

New Rear Axle Kit

Comes with 1 Bearing, 1 Seal & 1 Circle Clip / Snap Ring

Replaces OEM #s...
Bearing # 92045-1229 (BG139)
Seal # 92049-0049 (SE541)
Circle Clip # 92033-2149

Fits Kawasaki Mule 600 / 610

Price$29.00

-
+

Kawasaki Bayou KLF300 4x4 Tune-up Kit

Price$36.86

Kawasaki Bayou KLF300 4x4 Tune-up Kit

Product ID KDTK303

Kawasaki Bayou KLF300 4x4 Tune-up Kit

Includes:
Oil Filter 103
Air Filter OE 11013-1158
Spark Plug ND8EA
Carburetor Rebuild Kit 303

The carb rebuild kit contains everything you need to rebuild one Polaris carburetor.
Includes: Gaskets, O-Rings, Needles, Seats, Springs, Float Valve and Jets Fits Kawasaki Bayou 300 1989-2004 / Carburetor #'s 15001-1479, 15003-1076, 15001-1660.

Price$36.86

-
+

Kawasaki Mule 600 / 610 / SX Tune Up Kit 2011-2016

Price$99.00

Kawasaki Mule 600 / 610 / SX Tune Up Kit 2011-2016

Product ID PK60061011-15

Kawasaki Mule 600 & 610 2011-2015 Tune Up Kit Contains:

(1) Carburetor Rebuild Kit KCR610
(1) 11013-0037 Air Filter
(1) Aftermarket Air Filter replaces 11029-1004
(1) OF300 Oil Filter
(1) FF-07-062 Fuel Filter
(1) NGK Spark Plug BPR5ES

Price$99.00

-
+

XBRC3601 Kawasaki Front Brake Caliper Rebuild Kit

Price$21.95

XBRC3601 Kawasaki Front Brake Caliper Rebuild Kit

Product ID XBRC3601

Kawasaki Front Brake Caliper Rebuild Kit. Each kit includes all necessary
rubber componets and pad hanger pins, if applicable. Made by Nissin.
Fits:
Kawasaki *KLF300C 89-03
Kawasaki *KLF400 4x4 93-99
Kawasaki *KVF650 06-09
Kawasaki *KVF750 05-09
* requires one per wheel

Price$21.95

-
+

XCR300 Kawasaki Bayou 220 Carburetor Rebuild Kit

Price$24.95

XCR300 Kawasaki Bayou 220 Carburetor Rebuild Kit

Product ID XCR300

Contains everything you need to rebuild one carburetor.
Includes Gaskets, O-Rings, Needles, Seats and Jets
Fits:
Kawasaki Bayou KLF220 88-02

Price$24.95

-
+

XCR302 Kawasaki Bayou Carburetor Rebuild Kit

Price$19.95

XCR302 Kawasaki Bayou Carburetor Rebuild Kit

Product ID XCR302

Contains everything you need to rebuild one carburetor.
Includes Gaskets, O-Rings, Needles, Seats and Jets
Fits:
Kawasaki Bayou KLF300 2X4 89-04

Price$19.95

-
+

XCR310 Kawasaki Prairie Carburetor Rebuild Kit

Price$20.00

XCR310 Kawasaki Prairie Carburetor Rebuild Kit

Product ID XCR310

Contains everything you need to rebuild one carburetor.
Includes Gaskets, O-Rings, Needles, Seats and Jets.
Fits:
Kawasaki Prairie KFV360 03-13

Price$20.00

-
+

XMP733 Kawasaki Bayou 300 Fuel Tank

Price$259.95

XMP733 Kawasaki Bayou 300 Fuel Tank

Product ID XMP733

Plastic replacement gas tank for KLF300A 86-88.
*Note this tank is available in natural color only.
Replaces :
51001-1210

Price$259.95

-
+

XPK3746 - SET OF 2 KITS

Price$175.00

XPK3746 - SET OF 2 KITS

Product ID XPK3746

PISTON KIT NAMURA KAWASAKI KAF620 MULE 1.50 **SET OF 2

Price$175.00

-
+
